Nominal Pressure (PN)
The Pressures specified are in accordance to DIN 2401 part 1 draft. The pressure has a safety factor of 4 times according to DIN 3859 standards.
Pressure Range
- LL Series: Up to 100 Bar
- L Series: Up to 500 Bar
- S Series: Up to800 Bar
Compression Fitting Temperature ratings vary in accordance to the body material as per below:
Body Material Temperature Rating
- Stainless Steel:-60oC to 400oC (DIN 17440)
- Steel:-40oC to 120oC (DIN 3859)
- Brass:-60oC to 175oC
When combing seal material,then temperature ratings of seal may become the limiting factor on the fitting's temperature rating.Kindly refer to the temperature rating below:
Elastomer's Temperature Rating
- NBR:-35oC to 100oC (Default Option)
- Viton:-25oC to 200oC
- PTFE:-60oCCto 240oC
Presure Reduction in temperature
There are reductios in the nominal pressure(PN) caused by the temperature of the fluid medium or surroundings.
Please refer to the table below:
| Fitting Material | Temperature range | Pressure Reduction |
|---|---|---|
| Stainless Steel | -60°C to +20°C | - |
| stainless Steel | +50°C | 4% |
| stainless Steel | +100°C | 11% |
| stainless Steel | +200°C | 20% |
| stainless Steel | +300°C | 29% |
| stainless Steel | +400°C | 33% |
| Steel | -40°C to +120°C | - |
| Brass | -40°C to +175°C | 35% |
